Fraunhofer IMS develops extremely low-noise read out-ASIC for capacitive sensors

Press release /

Proportion: The "IMS-CAP51" sensor on a fingertip

Extremely low-noise, highly precise: Those are the prominent characteristics of the »IMS-CAP51«.
The new IMS-CAP51 adds these »merits« to the read-out of capacitive sensors, for example of acceleration-MEMS. Its special talents come into effect where highly accurate measured data is of great importance: for example seismic measurements for the early detection of earthquakes. The fundamental mode of operation: The IMS-CAP51 of the Fraunhofer Institute for Microelectronic Circuits and Systems IMS is connected to a capacitive acceleration- MEMS (Micro Electronic Mechanical System) on a printed circuit board. Acceleration forces affect this MEMS, which hence generates a capacity- gap. The ASIC converts the measured capacity-gap into voltage. Eventually, this voltage is translated into a digital measurement-value by an analog to digital-converter. The ASIC can be delivered with an analog-digital-converter if requested.

What is special about this new development from the business unit »ASICs« of the Fraunhofer IMS?

»The core task was to develop a read-out circuit where the input-based noise is extremely low« describes Dr.-Eng. Alexander Utz, head of the project ASIC-development, the initial situation. Because: the higher the noise, the less reliable the measurement results. The task is solved after two years of time. The Fraunhofer-Team has achieved a very low input-based noise- with a concurring broad range (0 Hz- 15 kHz). The input-based noise is located at values beneath 50 zF/rt-Hz- therefore the new IMS-CAP51 of the Fraunhofer IMS from Duisburg holds the world-record!
Those results were obtained by the experts by executing the capacity-voltage conversion as a AC-paired Chopper-amplifier. »With this method, the 1/f-noise, which is dominant at semi-conductor circuits and is especially disruptive at lower frequencies, can be confined, respectively suppressed effectively«, explains Dr.-Eng. Alexander Utz.

Now the ASIC can be applied where especially delicate measurements with weak signals have to be carried out. Customer-specific realizations for special requirements are gladly implemented by the Fraunhofer IMS in accordance with the customer. This opens up diverse application fields. Applied in early-detection systems for earthquakes or Tsunamis it can supply information about vibrations in the earth early and precisely. Such seismic measurements are also helpful to the search of oil-and gas fields. Vibration profiles are recorded, which allow conclusions about potential oil-and gas resources. The ASIC can also be applied to measure vibration in course of monitoring building foundations. In connection with a positioning-sensor the ASIC can also be utilized for the alignment of antennas- by using the effects of earth’s gravity onto the sensor.
